HN-200C Leeb Hardness Tester
Product Notes:
All BRK meters and probes ship direct from the manufacturer and require 10-15 business days for shipping.
Custom options and configurations are also available. Please contact us if you need help with your specific application.
Download
Download
HN200C Leeb Hardness Tester from BRK NDT is a professional portable solution for field testing large components (2kg+/5mm+) in machining, molds and heavy industry.
The HN200C Leeb Hardness Tester is a high-precision, portable hardness testing device designed for large and heavy workpieces (weighing over 2kg and thickness exceeding 5mm). It features 7 hardness scales, 7 impact devices, 360° testing and data storage of up to 500 test results. Ideal for pressure vessels, turbines etc. It supports seven hardness unit conversions, delivers instant readings without manual calculations and requires no calibration. With its rugged design and advanced features, this tester is the ideal solution for industrial hardness measurement applications.
- Wide Compatibility – Measures hardness on large, heavy workpieces (2kg+, 5mm+ thickness)
- 7 Hardness Units – Direct conversion between HL, HRC, HRB, HB, HV, HRA, and HS scales
- 7 Interchangeable Impact Devices – D, DC, DL, D+15, C, G, E types for different material applications
- No Calibration Needed – Ready to use right out of the box
- High-Resolution LCD – Clear readings with intuitive operation
- 360° Impact Direction – Test from any angle including vertical downward
- 500 Reading Data Storage – Stores measurement results for documentation and analysis
- USB Data Transfer – Easily export data to PC for further processing
Applications
- Metalworking Industry – Quality control for castings, forgings and welded structures
- Mold Manufacturing – Hardness testing of mold cavities and cores
- Heavy Machinery – Component inspection for construction and mining equipment
- Pressure Vessels/Pipelines – Material verification and in-service inspection
- Power Generation – Turbine blades, generator components and boiler parts
- Aerospace – Aircraft components and landing gear testing
- Automotive – Engine parts, transmission components and chassis inspection
-
Rail Transportation – Wheel set and rail testing
- Research Labs – Material development and failure analysis
Why Choose the HN200C Leeb Hardness Tester?
Time-Saving Operation – Instant results eliminate manual calculations
Exceptional Versatility – Covers nearly all metallic materials with 7 impact devices
Superior Accuracy – ±4 HL (HLD) for reliable measurement results
Rugged Construction – Withstands harsh industrial environments
User-Friendly Design – Lightweight (200g) with ergonomic grip
The HN200C is the professional choice for engineers and inspectors in manufacturing, energy, transportation and other industries requiring fast, reliable hardness testing. Its combination of portability, accuracy and durability makes it an indispensable tool for quality assurance and maintenance programs.
|
Probe Type |
Applicable Scenarios |
Indication Error and |
|
D |
Standard configuration for routine measurements |
760±30HLD,±6HLD 530±40HLD,±10HLD |
|
DC |
Suitable for measuring the inner side of the pipe wall |
760±30HLDC,±6HLDC 530±40HLDC,±10HLDC |
|
DL |
Suitable for measuring slender narrow slots or holes |
878±30HLDL,±12HLDL 736±40HLDL,±12HLDL |
|
D+15 |
Suitable for surfaces with grooves or indentations |
766±30HLD+15,±12HLD+15 544±40HLD+15,±12HLD+15 |
|
G |
Suitable for heavy and rough surface castings and forgings |
590±40HLG，±12HLG 500±40HLG，±12HLG |
|
C |
Suitable for small and lightweight components and surface hardening layers |
822±30HLC，±12HLC 590±40HLC，±12HLC |
Specifications
|
Measurement range |
HS (30.6-10.2.6), HLD (170-960), HB (19-651), HRB (13.5-101.7), HRC (17.9-69.5), HRA (59.1-88), HV (80-1042) |
|
Measurement direction |
360 ° omnidirectional |
|
Applicable materials |
steel and cast steel, alloy tool steel, stainless steel, gray cast iron, ductile iron, cast aluminum alloy, copper zinc alloy, |
|
Indicating error |
± 1.5HRC |
|
Repeatability of indication |
1.5HRC |
|
Upper and lower limit setting range |
(170-960) HLD |
|
Display |
High brightness OLED128 * 64 dot matrix display |
|
Data storage |
up to 500 groups |
|
Data export capability |
RS232 |
|
Working voltage |
2×1.5V alkaline battery |
|
Continuous working time |
approximately 100 hours |
|
Working temperature |
-10 ℃~55 ℃ |
|
Relative humidity |
≤ 90% |
|
Package size |
30*25*15CM |
|
Host size |
185*75*35MM |
|
Net weight |
3KG |
|
Gross weight |
3.3KG |
|
Shell material |
ABS+PC plastic |
